SEW-Eurodrive gear motor SF37 DT71D4/BMG/Z

Article no.: 01.3017528901.0001X01
12 months guarantee
gear motor SF37 DT71D4/BMG/Z
gear motor SF37 DT71D4/BMG/Z
gear motor SF37 DT71D4/BMG/Z
gear motor SF37 DT71D4/BMG/Z
gear motor SF37 DT71D4/BMG/Z
gear motor SF37 DT71D4/BMG/Z
All images are original images.
428,00 € net*
In stock: 1 piece
? Display cart in PayPal
Article no.: 01.3017528901.0001X01
Shipping: Express delivery possible
Guarantee in months: 12
Stock: 1
* Prices excl. VAT plus shipping costs

Specification

Manufacturer
SEW-Eurodrive
Guarantee in months
12
Frequency
50 Hz
Rotation Speed
1380 U/min
Power
0,37 kW
Voltage
230 / 400 V AC
Current
2,0 / 1,15 A
Protection Class (IP)
54
Holding Brake
400 V AC, 5 Nm
Shaft Diameter
20 mm
Shaft End
M6
Feather Key
6 x 30 mm
Flange Diameter
80 mm
Diameter Of Pitch Circle
100 mm, 4 x 6,3 mm
Speed (gear)
22 U/min
Transmission
63,33
Torque
103 Nm
Weight
17.93 kg
Stock location
Rosenfeld
Stock ground
P13A1-L
