RW-Elektronik Power drive card for 3-phase stepping motors SM3 130 05 0300 R056

Article no.: 5382000153
12 months guarantee
Power drive card for 3-phase stepping motors SM3 130 05 0300 R056
Power drive card for 3-phase stepping motors SM3 130 05 0300 R056
Power drive card for 3-phase stepping motors SM3 130 05 0300 R056
Power drive card for 3-phase stepping motors SM3 130 05 0300 R056
Power drive card for 3-phase stepping motors SM3 130 05 0300 R056
Power drive card for 3-phase stepping motors SM3 130 05 0300 R056
All images are original images.
398,00 € net*
In stock: 1 piece
? Display cart in PayPal
Article no.: 5382000153
Product condition: Used from old stock
Shipping: Express delivery possible
Guarantee in months: 12
Stock: 1
* Prices excl. VAT plus shipping costs

Mat.Nr.:11080751

Used item. New items and other device versions upon request.

Specification
Pin compatible replacement for BERGER LAHR D900.51 card
Supply voltage: 80-140VDC
Motor phase current (settable): 1.35-5.5A
Steps/revolution (settable): 200, 400, 500, 1000, 2000, 4000, 5000, 10000
Automatic current reduction at pulse frequencies: <10Hz IN x 0.5
Signal input (opto coupler) voltage: 5V
Signal input current: ca.10-20mA
Ready output: Relay dry contact 36VDC/200mA
Dimensions (in mm): 100 x 160 x 51
Weight: ca. 0.5 kg

Specification

Product condition
Used from old stock
Function
Tested
Manufacturer
RW-Elektronik
Guarantee in months
12
Weight
0.5 kg
Stock location
Rosenfeld
Stock ground
A18A01-BFL
